Welding Equipments

Hose Balancers 9200/9203 – Capacity 0,4/5 kg

Aluminium body.
Maximum ease of use.
Minimum overall dimensions as the tool is supported by the hose.
Polyurethane hose.
Rugged construction, cast aluminium body.
Adjustable capacity.
Springs properly sized to ensure long life and smooth running.
Adjustable stroke limiting device.
Auxiliary safety suspension.
Max operating pressure 8 bar
Max operating temperature 50 °C.

Types

Clear

Main Features

Technical Sheet

Main Features

Technical Sheet

ITEM		9200	9201	9202	9203
Capacity	kg	0.4-0.8	0.75-1.5	1.2-2.5	3-5
Stroke	mm	1350	1350	1350	900
Net weight	kg	1.25	1.30	1.35	1.35
Gross weight	kg	1.40	1.40	1.60	1.60
Hose		Polyurethane
Package dimensions	mm	225 160 110	225 160 110	225 160 110	225 160 110

Specifications subject to change without notice.
